TBS M10Q GPS GLONASS
Current sensor for the TBS CORE. This is the 25A version. It’s compatible with other OSDs as well although we can’t take responsibility for that.
Try Fpv Shopping Event
Hurry and get discount up to 5%
Sale_coupon_15
₹1,498.00
14
People watching this product now!
- Warranty 1 year
- Free 30-Day returns
Payment Methods:
Description
Specification
- Chipset – ublox UBX-M10050
- Flash memory for saving configuration.
- Frequency – L1, 1575.42MHz ; L2,1561.10MHZï¼›L3,1602.00MHZ
- Baud Rate – 4800bps-921600bps, default 115200bps
- Channel – N/a
- Sensitivity – (Tracking: -166dBm) | (Capture: -160dBm) | (Cold Start – 148dBm)
- Cold start – Average 26 seconds
- Warm start – Average 24 seconds
- Hot start – Average 1 second
- Accuracy – (HorizontalPosition:Autonomous<2m average) | (SBAS < 2.0m average) | (Timepulse signal: RMS 30 ns)
- Maximum height – 50000m
- Maximum speed – 500 m/s
- Maximum acceleration – ≦ 4G
- Refresh Rate – 0.25Hz-18Hz, default 1Hz
- Size – 25 x 25 x 7.7mm
- Weight – 13.5g
- Input Voltage – 5V
- Magnetometer: QMC5883
